The role of carbon capture and storage in limiting warming to 1.5C

Key points

• Retrofitting existing fossil fuel assets with CCS is being proposed as one option to reduce the amount of emissions already locked in by existing infrastructure
• But high costs, and the plummeting cost of renewables, is eroding the economic case for retrofitting existing fossil fuel power plants with CCS. In most cases, earlier retirement of assets would be more economically efficient than retrofits
• CCS technologies remain stagnant and costly, and push up the cost electricity when used in power generation
• Questions over geological storage and water availability further undermine CCS as a solution for existing fossil fuel assets.
• Only one out of the existing 26 operational carbon capture and storage (CCS) projects is in the power sector. The majority of existing CCS projects are in the oil and gas sector as a part of enhanced oil recovery

Existing fossil fuel infrastructure will put 1.5°C out of reach

Energy infrastructure has an extremely long lifetime. Coal and gas-fired power plants have historically operated on average for 39 and 36 years respectively. If all energy infrastructure continues to operate until the end of its typical lifetime, cumulative global emissions between 2020-2050 would amount to 650 Gt CO₂, according to the IEA’s Net Zero by 2050 report. This is 30% more than the remaining carbon budget, estimated at 500 Gt CO₂, that is consistent with limiting global warming to 1.5°C (with a 50% likelihood) by the IPCC Working Group I report. As a result, alignment with 1.5°C means no new coal, gas or oil extraction, while existing demand for unabated coal must decline by 98% to just 1% of total energy use by 2050.

The electricity sector accounts for more than 50% of the total emissions from existing fossil fuel assets, 40% of which comes from coal-fired power plants alone. Therefore, existing assets face four main choices in order to stay within the remaining carbon budget:

1. Accelerating retirement (in scenarios that limit warming to 1.5°C, global coal and gas power generation’s operational lifetime are shortened to nine and 12 years respectively)
2. Reducing utilisation
3. Switching to low carbon fuel sources
4. Retrofitting with CCS

Carbon capture retrofits cannot compete with the plummeting cost of renewables

As of 2021, the costs for new solar PV and onshore wind are increasingly undercutting existing coal-fired power plants. Data from the IRENA Renewable Cost Database show that between 2010 and 2020, the cost of electricity from utility-scale solar photovoltaics (PV) fell 85%, from concentrated solar power by 68%, from onshore wind by 56% and from offshore wind by 48%.

Retrofitting plants with CCS is very costly – CCS for coal or gas electricity generation facilities are almost double the capital cost of power generation projects without CCS. Rapidly falling costs in wind and solar energy are eroding the economic value of CCS as a mitigation option by up to 96%, according to a paper published by the Grantham Institute.

The Boundary Dam CCS power plant project in Canada is the only commercially operational CCS coal power station in the world today (the only other operational CCS project for the power generation sector, Petra Nova, was shut down in 2020 as a result of high operational cost). The technology is installed on one 110MW boiler (small in comparison to typical project sizes of 500MW). It cost of USD 1.5 billion, of which $800 million was for the installation of the CCS technology and the remaining USD 500 million for retrofit costs. A leaked internal memo from November 2014 suggests the project has “serious design issues”, having suffered numerous technical problems in its first year. Even in 2021 it was only running at an average of ~30% capacity. Since 2014, it has only captured 4.3 Mt of CO₂, compared to its total theoretical CO₂ capture capacity of 1 Mt a year.

CCS is an extremely energy-intensive process, and the higher fuel requirement for the process adds further to the operational cost of plants. A 2017 study looking at potential applications of CCS on Indian power plants, for example, estimated that the costs of electricity would increase by 63-76%.

While renewable energy is expected to continue to decline in cost, CCS development has remained stagnant in the last 30 years. Currently there are only 26 operational CCS projects in the world, with only one facility in the power generation sector. On the carbon storage side, the vast majority (20 out 26) of projects use the captured CO₂ for enhanced oil recovery (EOR), rather than permanent geological storage. Captured CO₂ used for EOR undermines emissions cuts, where emissions from burning recovered oil could more than offset the benefits of capturing the CO₂ in the first place by a factor of up to three. Research indicates that tonnages of CO₂ injection are often overestimated, or facilities have stopped injecting sooner than is reported.

The additional capital and operational costs in power generation increase the cost of electricity, which can create cost barriers to energy access in developing countries. As such, CCS deployment should focus on capturing CO₂ in industry for permanent geological storage, rather than on retrofitting fossil fuel power generation.

Water and geological storage further constrain the application of CCS retrofits

The availability of large volume, permanent, geological reservoirs is critical for the cost effective removal and storage of CO₂. The amount of storage space accessible is still to be determined at a global scale. Not only does storage need to be permanent, it also needs to be close to, or within transportable distance from, the point of emissions to make projects viable. The mismatch between the locations of existing power plants and geological location of underground storage is one of key barriers to retrofitting the global fleet of power plants. A study of Indian emission sources indicates that only 14% of Indian emissions are in sites that are located within a range of 100km from geological sink locations.

CCS is a resource-intensive technology requiring a large amount of water for operations. It has been estimated that CCS can increase power plants’ water withdrawal by 175% and water consumption by up to 150%, compared to plants without CCS. With climate change, regions already prone to water scarcity may experience worsening periods of drought, further limiting the deployment of CCS in power plants in those regions.
